Factory sale Synchronous AC 50kw leroy somer brushless alternator with avr

Product Description

Product Description Factory sale Synchronous AC 50kw leroy somer Brushless Alternator with avr Alternator Products Specifications:
MODEL 3-PHASE 50Hz /1500RPM 380V-440V  3-PHASE 60Hz /1800RPM 440V-480V  DIMENSION WEIGHT
(KVA) (KW) (KVA) (KW) CM KG
WP164A 8.1 6.5 10.2 8.2 64×54×72 95
WP164B 11 8.8 13.8 11 64×54×72 102
WP164C 13.5 10.8 16.9 13.5 64×54×72 110
WP164D 16 12.8 20 16 64×54×72 116
WP184D 18.7 15 22 18 84×59×75 120
WP184E 22.5 18 28.8 23 84×59×75 133
WP184F 27.5 22 34.4 27.5 84×59×75 156
WP184G 31.3 25 37.5 30 84×59×75 172
WP184H 37.5 30 46.9 37.5 84×59×75 226
WP184J 40 32 50 40 84×59×75 236
WP224C 42.5 34 52.5 42 96×66×102 275
WP224D 50 40 62.5 50 96×66×102 295
WP224E 60 50 70 56 96×66×102 315
WP224F 75 60 87.5 70 96×66×102 345
WP224G 87.5 70 97.5 78 96×66×102 385
WP274C 100 80 118 94 126×76×102 415
WP274D 115 92 138 110 126×76×102 435
WP274D1 125 100 137.5 110 126×76×102 450
WP274E 140 112 168 134 126×76×102 485
WP274F 160 128 190 152 126×76×102 530
WP274G 175 140 213 170 126×76×102 580
WP274H 200 160 245 196 126×76×102 630
WP274J 230 184 281 224.8 130×76×102 750
WP274K 250 200 299 239.2 130×76×102 760
WP444C 250 200 294 235 151×79×107 880
WP444D 295 236 350 280 151×79×107 950
WP444E 325 260 394 315 151×79×107 1065
WP444FS 380 304 456 365 151×79×107 1145
WP444F 400 320 480 384 151×79×107 1185
WP544C 450 360 550 440 165×95×116 1350
WP544D 500 400 594 475 165×95×116 1450
WP544E 600 480 713 570 165×95×116 1700
WP544FS 625 500 725 580 165×95×116 1753
WP544F 670 536 775 620 165×95×116 1820
WP634B 750 600 855 684 180×100×145 2020
WP634C 800 640 916 732.8 180×100×145 2050
WP634D 910 728 1034 834.2 180×100×145 2100
WP634E 1000 800 1145 916 180×100×145 2260
WP634F 1130 904 1274 1019.2 180×100×145 2490
WP634G 1250 1000 1386 1108.8 180×100×145 2820
  WESTINMA POWER Series Synchronous Brushless Alternator are made adopted Stamford alternators technology and according to the standards of GB755,IEC60034,NEMA etc. The alternators have standard features: voltage adjust, stability adjust, under frequency roll off, over exciting protection, low radio interference, etc. The stators are 2/3 pitch winding, the rotors are fixed sequential damper winding. The stator core is designed landler taking advantage of CAD, ensuring a very low waveform distortion. ”H” class insulation system is provided the high build required for static windings and the high mechanical strength required for rotating components. ELECTRIC FEATURES Insulation Class H all regulatory components are made up with special materials and are immersed in lacquer by peculiar tech. Vanish and colophony materials are develop to strengthen the processing and machinery intensity of windings and revolving parts for protecting the alternator work under corrosive environment. Winding and electric features 2/3 pith winding design can effectively eliminate the third harmonic wave(3th.9th,15th) of the voltage ,which is the best design of UPS for nonlinear load .Connected with the network in parallel, the structure can restrain excessive currents in the midline. This and the 2/3 pitch help to check the wave distortion and output voltage. Phone interference and Radio interference THF (defined by 40thpart of BS4999) <2%.TIF<50 Brushless apparatus and quality AVR ensure little radio interference in transmission. RFI noise filter is also available. Manufacturing Standard GB755, BS 5000, VDE 0530, NEMA MG1-22, IEC34 Warranty policy WESTINMAN POWER product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable Spare parts of alternator caused by our quality of production or raw material. After expiration, our provide cost spare parts maintenance of alternator. Packaging & Shipping   Company Information     FAQ   FAQ Q . How much will the shipping of my order cost ?
Our shipping costs are calculated depending on the total weight and measurement CBM of the items you wish to purchase and your destination .We always do our best to keep the shipping costs to a minimum .Our forwarder has a long contract with us ,we can get a big discount for you .
  Q . How long does a sample takes ?
If we have in stock , a sample will be delivered less than 2 days .
Usually a sample takes 7 days .More please contact us immediately .
  Q . What is the MOQ of the product ?
MOQ 1pc, Special models be negotiated.   Q . Do you accept OEM ?
Yes , we supply OEM service.

Contact us if you need more details on leroy somer brushless alternator. We are ready to answer your questions on packaging, logistics, certification or any other aspects about brushless alternator avr、50kw brushless ac alternator. If these products fail to match your need, please contact us and we would like to provide relevant information.
